สเต็ปเปอร์มอเตอร์ Nema17 Stepper Motor 42 Hybrid Stepper Motor 2 Phase 17HS2408 พร้อมสายไฟ
฿195
฿97
SAVE 50%
โปรโมชั่นจำกัดเวลา สั่งซื้อด่วนก่อนสินค้าหมด!
ร้านค้า General4_Group
แบรนด์NoBrand
การจัดส่ง ส่งฟรีทั่วไทย
รายละเอียดสินค้า
NEMA17 Stepper Motor 42 Hybrid Stepper Motor 2 Phase 17HS2408
สเต็ปเปอร์มอเตอร์ Nema17 Stepper Motor 42 Hybrid Stepper Motor 2 Phase 17HS2408 พร้อมสายไฟ เป็นมอเตอร์ที่ใช้สำหรับควบคุมการหมุน เพื่อกำหนดตำแหน่งการทำงานที่มีความแม่นยำสูง ขับเคลื่อนไปทีละ Step โดยสามารถหมุนได้รอบแกน 360 องศา นิยมใช้สำหรับงานระบบควบคุมในหุ่นยนต์, 3D Printer, Mini CNC เป็นต้น
คุณสมบัติ สเต็ปเปอร์มอเตอร์ Nema17 Stepper Motor 42 Hybrid Stepper Motor 2 Phase 17HS2408:
Model 17HS2408
Step torque angle 1.8 (5%)
Current 0.6A
Resistance 8 (10%)
Inductance 10mH (20%)
Holding torque 12N.cm
Braking torque 1.6N.cm
Rotor inertia 34g.cm
Number of lead 4
Length of motor 28mm
Length of wire 375mm
Shaft diameter 5mm
Length of shaft 21mm
Working temperature -20 to 50℃
Insulation resistance 100M 500V DC
Electric strength 820V AC/Min
Radial clearance 0.02Max (450 load)
Axial clearance 0.08Max (450 load)
Stepper 17HS2408 Features:
- Low noise and stable.
- Good accelerating performance.
- Durable and long service life.
