DT-06 ESP8266 TTL to WiFi ESP8266 + HC06 Module TTL to WiFi ESP-M2
รายละเอียดสินค้า :
1. Fully compatible with the original electrical interface and physical interface for the serial transparent Bluetooth;
2. Built-in the high performance WiFi module ESP-M2 with size: 34mm*17mm*4mm;
3. Working voltage: 4.5V~6.0V, TTL working voltage: 3.3V (compatible with 5.0V);
4. Provided pins: STATE, TXD, RXD,EN;
5. Average current: 80mA; when data sent, it is 170mA; but it is 20A at deep sleep mode;
6. Support serial AT command;
7. Support re-programmable, OTA firmware update;
8. Seamless transparent transmission between serial and WiFi;
9. Built-in HTTP Web Server, support configure parameters by web page;
10. Support re-connect automatically at WiFi STA mode and TCP Client;
11. Support set baud rate, data bit, parity check, stop bits, and/or subcontracting time;
12. Support baud rate (bps): 300/600/1200/2400/4800/9600/19200/38400/57600/74800/115200/230400/460800/921600/1843200/3686400;
13. Support AP enable, self-defined SSID/password, self-defined IP and network duration;
14. Automatically scan the peripheral WiFi hotspot, support STA enable,DHCP, self-defined IP;
15. Support TCP Server, TCP Client, UDP Server, UDP Client and UDP local broadcast;
16. Support DNS resolution automatically for the remote sever address;
17. Support checking the status by AT command;
18. Provide IO4 to show the WiFi status;
19. Working temperature: -40-125;
